AMD Ryzen 5 7500X3D 6-Core 4.0GHz AM5 Desktop Processor 3D V-Cache 65W Box

AMD Ryzen 5 7500X3D CPU - AMD Ryzen 5 6-Core 4GHz Socket AM5 Processor

Features:

• AMD Ryzen 5 7500X3D Processor with 102MB 3D V-Cache
• Up to 4.5GHz Boost Clock
• 6 Cores, 12 Threads
• AMD 5nm Zen 4 Architecture
• TSMC 6nm I/O Die
• Advanced 3D Chip Stacking Technology
• 384KB L1 Cache
• 6MB L2 Cache
• 96MB L3 Cache
• Integrated Radeon RDNA 2 Graphics
• Supports AMD X870E, X870, B850, B840, X670E, X670, B650E, B650, A620 Chipsets
• Dual-Channel DDR5 Memory Architecture Up to 128GB
• Up to DDR5-5200MHz Supported
• PCI Express Version 5.0 Supported
• AMD EXPO Memory Overclocking Profiles
• AMD Precision Boost 2.0 & Precision Boost Overdrive
• AMD StoreMI Technology
• 65W TDP
• Socket AM5 Compatible
• 3 Year Warranty

Technical Specifications:

Name
AMD Ryzen™ 5 7500X3D

Family
Ryzen

Series
Ryzen 7000 Series

Form Factor
Desktops, Boxed Processor

Market Segment
Enthusiast Desktop

AMD PRO Technologies
No

Regional Availability
NA, EMEA

Former Codename
Raphael AM5

Processor Architecture
Zen 4

Number of CPU Cores
6

Multithreading (SMT)
Yes

Number of Threads
12

Max Boost Clock
Up to 4.5 GHz

Base Clock
4 GHz

L1 Cache
384 KB

L2 Cache
6 MB

L3 Cache
96 MB

Default TDP
65W

Processor Technology for CPU Cores
TSMC 5nm FinFET

Processor Technology for I/O Die
TSMC 6nm FinFET

CPU Compute Die (CCD) Size
71mm²

I/O Die (IOD) Size
122mm²

Package Die Count
2

AMD EXPO Memory Overclocking Technology
Yes

Precision Boost Overdrive
Yes

Curve Optimizer Voltage Offsets
Yes

AMD Ryzen Master Support
Yes

CPU Socket
AM5

Supporting Chipsets
A620, X670E, X670, B650E, B650, X870E, X870, B840, B850

CPU Boost Technology
Precision Boost 2

Instruction Set
x86-64

Supported Extensions
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution
Not Included

Recommended Cooler
Liquid cooler recommended for optimal performance

Max Operating Temperature (Tjmax)
89°C

Launch Date
11/12/2025

OS Support
Windows 11 64-Bit, Windows 10 64-Bit, RHEL x86 64-Bit, Ubuntu x86 64-Bit

Connectivity
Native USB 3.2 Gen 2 (10Gbps): 4
Native USB 3.2 Gen 1 (5Gbps): 0
Native USB 2.0 (480Mbps): 1

PCI Express Version
PCIe 5.0

Native PCIe Lanes (Total/Usable)
28, 24

NVMe Support
Boot, RAID0, RAID1, RAID10

System Memory Type
DDR5

Memory Channels
2

Max Memory
128 GB

System Memory Subtype
UDIMM

Max Memory Speed
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600

ECC Support
Yes (Requires motherboard support)

Graphics Model
AMD Radeon Graphics

Graphics Core Count
2

Graphics Frequency
2200 MHz

USB Type-C DisplayPort Alternate Mode
Yes

Product ID Tray
100-000001904
