Cooler Master Elite Gold 750W 80 PLUS Gold Fully Modular ATX 3.1 PSU PCIe Gen 5.1

Cooler Master Elite Gold 750W 80 PLUS Gold Modular ATX 3.1 Power Supply

Essential Gold Power for Everyday Gaming Builds

Features:

• Supports ATX 3.1 and PCIe Gen 5.1 standards
• Ideal for RTX 50 GPUs
• Stable performance under high loads at up to 40°C
• Quiet rifle bearing fan for efficient cooling and low noise
• 750W output with 80 Plus Gold-certified efficiency
• Fully modular embossed cable design
• Reliable 10-year warranty

ESSENTIAL GOLD POWER FOR EVERYDAY GAMING BUILDS

Cooler Master Elite Gold 750 is designed for reliable everyday gaming builds. With full ATX 3.1 and PCIe 5.1 support, it ensures stable performance and compatibility with the latest and upcoming mid-range GPUs. Offering 80 Plus Gold efficiency, dependable operation at up to 40°C, and a quiet rifle bearing fan, it delivers efficient and quiet power. A compact 140mm form factor makes installation easy across a wide range of cases, while fully modular embossed cables simplify cable management. Backed by a 10-year warranty, the Elite Gold 750 provides lasting confidence and stability for your system.

HIGH TEMPERATURE RESILIENCE

Operates reliably at up to 40°C, perfect for extended gaming, rendering, and overclocking.

Compatible with ATX 3.1 and PCIe Gen 5.1

ATX 3.1 delivers tighter voltage and current regulation with peak power support up to 200%* of its rated output, making the Elite Gold 750 ready for the latest and upcoming mid-range GPUs.

• All performance stats confirmed in 25°C ambient temperature testing.*

RIFLE BEARING FAN

The rifle bearing fan offers a longer lifespan while providing better noise reduction for consistent, reliable cooling.

• All performance stats confirmed in 25°C ambient temperature testing.*

80 PLUS GOLD CERTIFIED EFFICIENCY

Cooler Master Elite Gold 750 achieves over 90% efficiency at typical loads, helping reduce energy waste and minimize heat generation.

• All performance stats confirmed in 25°C ambient temperature testing.*

COMPACT FORM FACTOR

Unlike typical high-wattage PSUs that extend beyond 150mm, the Elite Gold’s compact design at 150mm or less ensures easy installation across a wide range of cases, making it ideal for space-conscious PC builds.

Fully Modular Embossed Cable Design

The fully modular design comes with flat black cables that can be tailored to each build, offering enhanced grip and a premium look for easier management and a cleaner overall setup.

Technical Specifications:

General

Model: MPX-7505-AFAG
Series: Elite Series
Category: Above 750 W
Form Factor: ATX
ATX Version: ATX 12V Ver. 3.1
Modular: Fully Modular
Rated Power: 750 W

Power Input

Input Voltage: 100–240 V
Input Current: 10–5 A
Input Frequency: 50–60 Hz
PFC: Active PFC

Performance

Efficiency: ≥90% @ Typical Load
80 PLUS Rating: 80 PLUS Gold
ErP 2014 Lot 3: Yes
Power Good Signal: 100–150 ms
Hold-Up Time: >11 ms
MTBF: >100,000 Hours @ 25℃ ambient

Cooling

Fan Size: 120 mm
Fan Bearing: Rifle bearing

Protection Features

Protections

• UVP
• OVP
• OPP
• OTP
• SCP

Connectors

• 1 × ATX 24-Pin Connector
• 1 × EPS 4+4-Pin Connector
• 1 × EPS 8-Pin Connector
• 2 × PCIe 6+2-Pin Connectors
• 1 × 12+4 Pin Connector
• 4 × SATA Connectors
• 2 × Peripheral 4-Pin Connectors

Environmental

Operating Temperature: 0 °C to 40 °C

Compliance and Certification

Regulatory Certifications

• cTUV us
• CB
• CE
• FCC
• BSMI
• CCC
• RCM
• UKCA
• BIS
• RoHS2.0

Physical

Dimensions (L × W × H): 140 × 150 × 86 mm
